Frappe Charts

GitHub-inspired modern, intuitive and responsive charts with zero dependencies

Explore Demos »

### Contents * [Installation](#installation) * [Usage](#usage) * [Updates](#updates) * [License](#license) #### Installation * Install via [`npm`](https://www.npmjs.com/get-npm): ```console $ npm install frappe-charts ``` and include in your project: ```js import Chart from "frappe-charts/dist/frappe-charts.min.esm" ``` * ...or include within your HTML ```html ``` #### Usage ```js const data = { labels: ["12am-3am", "3am-6pm", "6am-9am", "9am-12am", "12pm-3pm", "3pm-6pm", "6pm-9pm", "9am-12am" ], datasets: [ { title: "Some Data", type: "bar", values: [25, 40, 30, 35, 8, 52, 17, -4] }, { title: "Another Set", type: "line", values: [25, 50, -10, 15, 18, 32, 27, 14] } ] } const chart = new Chart("#chart", { // or a DOM element title: "My Awesome Chart", data: data, type: 'axis-mixed', // or 'bar', 'line', 'scatter', 'pie', 'percentage' height: 250, colors: ['#7cd6fd', '#743ee2'] }) ``` If you want to contribute: 1. Clone this repo. 2. `cd` into project directory 3. `npm install` 4. `npm run dev` #### Updates ##### v1.0.0 - Major rewrite out. Some new features include: - Mixed type axis datasets - Stacked bar charts - Value over data points - Y Markers and regions - Dot size, Bar space size, and other options - Legend for axis charts - We would be looking to incorporate existing PRs and issues in the meantime. ##### Please read [#93](https://github.com/frappe/charts/issues/93) for v0.1.0 updates on rework and development. ##### v0.0.7 - [Custom color values](https://github.com/frappe/charts/pull/71) for charts as hex codes. The API now takes an array of colors for all charts instead of a color for each dataset. - [@iamkdev's](https://github.com/iamkdev) blog on [usage with Angular](https://medium.com/@iamkdev/frappé-charts-with-angular-c9c5dd075d9f). ##### v0.0.5 - More [flexible Y values](https://github.com/frappe/charts/commit/3de049c451194dcd8e61ff91ceeb998ce131c709): independent from exponent, minimum Y axis point for line graphs. - Customisable [Heatmap colors](https://github.com/frappe/charts/pull/53); check out the Halloween demo on the [website](https://frappe.github.io/charts) :D - Tooltip values can be [formatted](https://github.com/frappe/charts/commit/e3d9ed0eae14b65044dca0542cdd4d12af3f2b44). ##### v0.0.4 - Build update: [Shipped](https://github.com/frappe/charts/pull/35) an ES6 module, along with the browser friendly IIFE. ##### v0.0.2 - We have an animated [Pie Chart](https://github.com/frappe/charts/issues/29)! Thanks [@sheweichun](https://github.com/sheweichun). - [@tobiaslins](https://github.com/tobiaslins) contributed tweaks for his quest to make these easy to use with React. Check out his [repo](https://github.com/tobiaslins/frappe-charts-react-example) and updates at [#24](https://github.com/frappe/charts/issues/24) to learn more :) - A new logo. ##### v0.0.1 - The very first version out, with animatable bars and lines, a percentage chart and a heatmap. GitHub-style. #### License This repository has been released under the [MIT License](LICENSE) ------------------ Project maintained by [Frappe](https://frappe.io). Used in [ERPNext](https://erpnext.com). Read the [blog post](https://medium.com/@pratu16x7/so-we-decided-to-create-our-own-charts-a95cb5032c97).
